Certus esse potes emere Factory Price Maximum Productivity Screw Partem Machinam ex RONEN. RONEN frigidum est fabricandi machinas (Fastener) fabrica et elit in Sinis. Technologiam habemus Taiwan fabrum campum team, et cum vigilantia et technica arte productionis processus, herba area circiter 15000+ quadratum metri est.
Princeps Productivity Screw Part Machina features:
1. Machina potest producere Truss Caput, Countersunk Caput, Pone Screw, Lignum stupra, Chipboard stupra, Sui tapping stupra, Flat Caput Hex Caput, Pan Caput, Hexagon Caput, Socket Caput, Puga Caput et sic in.
2. Ad praesens exemplar maximum ad X08100 pervenire potest, diameter 2.5mm-8mm, longitudo 6-127mm. Maxima celeritas machinae nostrae circa 270 pcs/min pervenire potest.
Parameter Product (specification)
|
Model |
D12-70 |
D12-150 |
D12-200 |
D12-250 |
D12-300 |
D12-450 |
D16-180 |
D16-450 |
|
Max.Blank Diameter (mm) |
Φ7.0-15 |
Φ7.0-15 |
Φ7.0-15 |
Φ7.0-15 |
Φ7.0-15 |
Φ8.0-16 |
Φ8.0-18 |
Φ8.0-18 |
|
Max.Blank Longitudo (mm) |
70 |
150 |
200 |
250 |
300 |
450 |
180 |
450 |
|
Max.Cut- off Longitudo (mm) |
90 |
170 |
220 |
270 |
320 |
480 |
210 |
480 |
|
Plaga (mm) |
120 |
190 |
250 |
300 |
330 |
550 |
240 |
550 |
|
capacitas (pcs/min) |
60-70 |
40-50 |
30-40 |
30-40 |
25-35 |
25-35 |
35-40 |
25-35 |
|
Main Die Diameter (mm) |
Φ80×120 |
Φ80×200 |
Φ88×260 |
Φ88×330 |
Φ88×360 |
Φ90×540 |
Φ98×220 |
Φ98×540 |
|
Punch Coepi Die Diameter (mm) |
Φ55×120 |
Φ60×180 |
Φ60×180 |
Φ60×180 |
Φ60×180 |
Φ60×270 |
Φ65×180 |
Φ60×270 |
|
Precisam Punch Die Diameter (mm) |
Φ55×120 |
Φ60×180 |
Φ60×180 |
Φ60×180 |
Φ60×180 |
Φ60×270 |
Φ65×180 |
Φ60×270 |
|
Abscise Die Diameter (mm) |
Φ35×45 |
Φ45×60 |
Φ45×60 |
Φ45×60 |
Φ45×60 |
Φ45×60 |
Φ60×80 |
Φ60×80 |
|
Dromonem Location (mm) |
16×50-125 |
18×60×125 |
18×60×125 |
18×60×125 |
18×60×125 |
18×60×125 |
20×60×125 |
20×70×125 |
|
Main Motor Power (kw) |
20HP/15kw |
25HP/18.5kw |
25HP/18.5kw |
25HP/18.5kw |
25HP/18.5kw |
25HP/22kw |
25HP/22kw |
25HP/22k w |
|
Magnitudo L*W*H/(mm) |
4.50×2.00×1.32 |
5.20×1.90×1.80 |
5.20×1.90×1.80 |
5.20×1.90×1.80 |
5.20×1.90×1.80 |
6.50×2.25×2.10 |
4.40×2.10×1.95 |
6.50×2.25×2/.10 |
|
Pondus (kg) |
8700 |
14000 |
14300 |
15000 |
15850 |
20800 |
20800 |
21000 |
Apparatus Details et complevit Products Propono
High Productivity Screw Part Faciens Machina producit RONEN MACHINERY. RONEN MACHINATIO peculiaris est fabricatio ad machinas frigidas fabricandas (Fastener) in Sinis.
High Productivity Screw Part Faciens Machina singula:
Alta Productivity Screw Partes Machinae effectas products completi sunt:
Product Function Propono Video
High Productivity Screw Part Faciens Machina opus ostendunt.
Testimonia
High Productivity Screw Part Faciens Machina : testimonium.
FAQ
Q: certificationem CE habes?
A: Ita, certificationem CE habemus.
Q: Quid de partus tempore?
A: Communiter intra XXX dies, sed pendet in tempore quantitatis et ordinis.
Q: Quae vis apparatus copia?
A: Vexillum virtutis copia in Sinis est 380V, 3P, 50Hz. Lorem ipsum etiam possimus.
Q: Quomodo sumptus de naves?
A: Sumptus navium pendet ex ratione quam vis bona adipisci. Partus exprimere solet modum celerrimum, sed est quoque methodus carissima. Shipping optima solutio est pro magna quantitate. Ad impensas naves exigendas, solum tibi accuratiorem informationem praebere possumus postquam quantitas, pondus ac methodus cognoscuntur. Quaeso, contact us pro maiori notitia.
Q:Do tibi praebere inspectionem exitus video?
A: Ita, video inspectionis exitum praebere.
